| Backing Material: | |
|---|---|
| Adhesive Type: | |
| Color: | |
Features
High temperature resistance (up to 280°C) short time.
Abrasion, flame retardant, puncture and tear resistant
UL Listed H180 File No. E237601
Application
Insulation for high temperature dry type transformers and masking of sensitive area for protection from thermal spray operations.
 |  |
Technical data
Backing Material | Fiberglass | |
Adhesive Type | Silicone | |
Color | White | |
Total Thickness | 180µm | |
Peel Adhesion | >8 | N/inch |
Elongation at break | 5 | % |
Tensile strength | >200 | N/inch |
Dielectric breakdown | >2.5 | KV |
Temperature resistance (30 min) remove without residue | 280 °C |
Storage | Store under normal conditions of 60° to 80°F (16° to 27°C) and 40 to 60% relative humidity in the original packaging material. |
Shelf life | To obtain best performance, use this product within 12 months from date of manufacture. |
Sizes | In 1000mm width log roll. All rolls can be slit from 2 mm to log roll width |
