| Backing Material: | |
|---|---|
| Adhesive Type: | |
| Color: | |
Features
The acrylic adhesive provides resistance to oils, strong solvents and other chemicals.
Application
Designed for insulation applications, coils/transformers and motor etc.
 |  |
Technical data
Backing Material | Fiberglass | |
Adhesive Type | Acrylic | |
Color | White | |
Total Thickness | 180µm | |
Peel Adhesion | >10 | N/inch |
Elongation at break | 5 | % |
Tensile strength | >200 | N/inch |
Dielectric breakdown | >2.5 | KV |
Temperature resistance (30 min) remove without residue | 150 °C |
Storage | Store under normal conditions of 60° to 80°F (16° to 27°C) and 40 to 60% relative humidity in the original packaging material. |
Shelf life | To obtain best performance, use this product within 12 months from date of manufacture. |
Sizes | In 1000mm width log roll. All rolls can be slit from 2 mm to log roll width |
